Product Description:
This 5.8GHz dual-antenna FPV receiver module is designed for reliable analog video signal reception in drone and FPV systems. Featuring a high-contrast 0.96” OLED display, 48-channel support, and smart frequency tuning based on RSSI values, it offers precise channel locking, real-time signal strength monitoring, and ease of use—ideal for both beginners and experienced pilots.
Key Features:
-
Wide Compatibility:
Supports Fatshark Dominator V1, V2, V3, HD1, HD2, HD3, HDO, HDO2, and Skyzone O4L, O4X goggles. (DJI V1/V2 goggles require adapter board.) -
Precise Frequency Tuning:
Supports 48 channels across the 5.8GHz band (A, B, E, F, R, L), including common frequencies like 5845 MHz, ensuring accurate signal matching. -
Real-Time OLED Display:
Integrated 0.96-inch OLED screen shows current channel and signal strength clearly for quick adjustments. -
High Sensitivity Receiver:
Built-in -98dBm RF module with buzzer provides strong reception and loss alerts. -
Smart Dual-Antenna Operation:
Uses module RSSI values to automatically switch between antennas, enhancing video stability. -
Compact & Portable:
Lightweight 23g design, measuring just 42.4mm × 28mm × 20.5mm, ideal for indoor and outdoor use.
Specifications:
-
Processor: ESP32 + 0.96" TFT LCD
-
Receiving Module: -98dBm RF receiver + buzzer
-
Operation Mode: Dual antenna auto-switching based on RSSI
-
Frequency Range: 5.8GHz, 48 channels (A/B/E/F/R/L bands)
-
Power Supply: 5V @ 450mA
-
Dimensions: 42.4 × 28 × 20.5 mm
-
Weight: 23g
Application Scenarios:
-
FPV Drones: Receive high-quality analog video transmission for real-time piloting.
-
Video Testing: Quickly verify and test analog video systems.
-
Wireless Communication Tuning: Used in broader wireless signal testing applications.
